1) 1 x USB 3.0 (Type A) port
- Allows for USB playback and firmware upgrade
over USB.
2 1 x USB (Type B) port
- Connects to the control computer for content publishing and screen control.
3) 1 x Gigabit Ethernet port
- Connects to the control computer, a LAN or public network for content publishing and screen control.
4) Powerful processing capacity
- Quad-core ARM A55 processor @1.8 GHz
- Support for H.264/H.265 4K@60Hz video decoding
- 1 GB of onboard RAM
- 16 GB of internal storage
5) Flawless playback
- 2 x 4K, 6 x 1080p, 10 x 720p, or 20 x 360p video playback
6) All-round control plans
- Enables users to publish content and control screens from a computer, mobile phone, or tablet.
- Allows users to publish content and control screens from anywhere, anytime.
- Allows users to monitor screens from anywhere, anytime.
7) Switching between Wi-Fi AP and Wi-Fi STA
- In Wi-Fi AP mode, the user terminal connects to the built-in Wi-Fi hotspot of the TB60. The default SSID is “AP+Last 8 digits of SN”, and the default password is “12345678”.
- In Wi-Fi STA mode, the user terminal and the TB60 are connected to the Wi-Fi hotspot of a router.
8) Synchronous and asynchronous modes
- In asynchronous mode, the internal video source works.
- In synchronous mode, the video source input from the HDMI connector works.
9) Synchronous playback across multiple screens
- NTP time synchronization
- GPS time synchronization (The specified 4G module must be installed.)
- RF time synchronization (The specified RF module must be installed.)
10) Support for 4G modules
- The TB60 ships without a 4G module. Users have to purchase 4G modules separately if needed.
- Network connection priority: Wired network > WiFi network > 4G network
- When multiple types of networks are available, the TB60 will choose a signal automatically according to the priority.
